Test principle

Machine vision technology:

automatic identify, classify and count the formed elements in urine with microscope automatic morphological methods.

Test items

Normal RBC, Standing RBC, Dysmorphic RBC, Normal WBC, WBCC, Pus Cell, Hyaline Cast, Granular Cast, WBC Cast, Squamous Epithelial Cell, Normal Epithelial Cell, Sperm, Calcium Crystal, Oxalate Crystal Bacteria, Yeast, Amorphous Urates, Mucus, etc.

Test speed

30 samples / hour.

Sample volume

Minimum urine volume: 2ml; Aspiration volume: 0.5ml

Sample treatment

The sample can be directly tested without centrifugation.

Flow cell

High accuracy, single channel flow cell (test channel)

Sampling method

Fully automatic rail-based sample loading, 10 samples can be loaded simultaneously.

Accuracy

≥ 95%

Repeatability test

CV < 10%

Contamination rate

< 0.05%

Report form

International universal quantitative unit, HPF & LPF, etc. Comprehensive graphic report, including dry chemical analysis and quantitative analysis of urine formed elements.

Measurement (L×W×H)

520×440×550 mm

Net weight

35 kg

Data interface

Two-way communication interface, can be connected with dry chemistry analyzer, printer and hospital management system

Power supply

AC 110 / 230 V, 50 / 60 Hz

Standard configuration

Built-in computer, screen, mouse, keyboard.
