Model

CAL-18L

CAL-23L

Capacity

18 L

23 L

Chamber dimensions

249 mm × 355 mm

249 mm × 450 mm

Product size

594 mm × 468 mm × 453 mm

Water capacity

3.5 L

Voltage

220 V / 50 Hz

Input power

1800 W

Sterilization temperature

121 ℃ / 134 ℃

Sterilization temperature difference

± 0.5 ℃

Temperature control accuracy

Temperature sensing control，≤ ± 1 ℃

Display

LED, real-time display of temperature, pressure, time, etc.

Program

B & D / Helix test program / Leak test program

Standard

European B standard

Locks

Double door lock protection, mechanical lock equipped with air lock, the machine cannot be opened when the pressure in the pot is not about to reach 0

Water tank

Open water tank

Water supply system

Open double water tank for disinfection and cleaning

Water quality testing

It can detect whether the water quality meets the requirements of this equipment

Special sterilization

Inactivation of AIDS, hepatitis B, mad cow virus and spore

Pulsating pre-vacuum

3 times pre-vacuum

Maximum vacuum

Not less than - 0.8 bar

Sterilization pressure

Maximum sterilization pressure ≥ 2.0 bar

Drying procedure

After intense vacuum drying, the residual humidity of the instrument < 0.2%

Cleaning procedure

Automatic cleaning of internal piping and steam generator

Sterilization records

Built-in USB / Connect a printer to print the sterilization record

Security

A safety valve is provided to ensure that the machine safely relieves the pressure in the pot in case of emergency, fault self-test

Fault alarm

Automatically display fault information and display fault alarms

The number of error messages

28

Sterilized items

It can be used to sterilize surgical instruments, dental instruments, glassware, injection instruments, fabrics, etc.
