Reaction principle

High luminosity cold light source reflection determination.

Wavelength

All the visible wavelengths.

Test speed

 514 strips/hour (affected by human factors and software version).

Data memory

 1000 results, including time and patient ID.

Environment requirements

Temperature 10°C - 30°C, optimal temperature 18°C - 25°C

Relative humidity

≤ 80%

Communication interface

RS-232 serial port, parallel printing interface.

Power supply

220 VAC ± 15%, 50 / 60 Hz

Fuse

250V 2A

Power

≤ 60 w

Net weight

7.5 kg

Dimensions

350 mm × 320 mm × 150 mm

Printer

Internal thermal printer, outer needle printer port.

Language

Chinese, English ( we can add other languages according to customer's demand).

Standard RS232C output

Port connect with computer.

Program memory

8 M + 512 K

RAM

32 M + 96 K

Reaction principle

High luminosity cold light source reflection determination.

Test items

Leucocyte, Nitrite, Urobilinogen, Protein, pH, Blood, Specific Gravity, Ascorbic Acid, Ketone, Bilirubin, Glucose, Micro Albumin.

Baud rate

9600 bps

Screen display

6.5 inch (touching) / 7 inch (touching) color LCD screen.

Test system

Using 6 wavelength cold light source, both sensitivity & veracity are improved, reduced the ambient light interference.

Auto correction ability

Correct the influence which result from urine pH value, gravity and color.
