Test parameters

Urobilinogen (UBG), Bilirubin (BIL), Ketone (KET), Blood (BLD), Protein (PRO), Nitrite (NIT), Leukocyte (LEU), Glucose (GLU), Specific gravity (SG), pH (pH), Ascorbic Acid (VC), Microalbumin (MAL)

Light wavelength

525 nm, 610 nm, 660 nm

Test principle

Photoelectric colorimetric method for strips, Refractometric method for color, turbidity, and specific gravity

Test speed

240 samples / hour (15 seconds / sample)

On board sample capacity

6 racks of 10 tubes (60 samples)

Sample volume

1 ml

Data storage capacity

20,000 samples

External output

RS-232

Power supply

AC 220 V, 50 Hz

Power

300 VA

Environment temperature

15°C ~ 35°C, optimal temperature 20°C ~ 25°C, relative humidity ≤ 75%,

Dimensions

660 mm × 625 mm × 581 mm (L × W × H)

Weight

65 Kg
