Model

DGL-35X

DGL-50X

DGL-75X

DGL-100X

Volume

35 L

50 L

75 L

100 L

Power

3.5 KW

3.5 KW

4.5 KW

4.5 KW

Voltage

AC 220 V, 50 HZ

Rated working pressure

0.22 Mpa

Rated working temperature

134 ℃

Sterilization temperature

50 ℃ ~ 134 ℃

Sterilization time setting range

4 ~ 120 min

Drying time setting range

0 ~ 240 min

Chamber volume (mm)

Ø 350 × 400

Ø 350 × 525

Ø 400 × 625

Ø 450 × 650

Bucket dimension (mm)

Ø 330 × 320

Ø 330 × 460

Ø 380 × 560

Ø 420 × 540

Basket dimension (optional)

Ø 320 × 350

Ø 320 × 240 × 2

Ø 360 × 280 × 2

Ø 410 × 300 × 2

Outer dimension (mm)

698 × 498 × 940

698 × 498 × 1110

770 × 570 × 1185

788 × 588 × 1255

Packing size (L × W × H) (mm)

790 × 610 × 1130

800 × 600 × 1230

840 × 610 × 1310

870 × 650 × 1380

Gross / Net weight

125 / 110 kg

130 / 112 kg

145 / 114 kg

156 / 129 kg
