Application

Modular Design

Compatible Surgical Procedures

With monopolar and bipolar function,4MHz radio wave technology

Wide clinical applications, such as the general surgery, cosmetic procedures, ENT, gynecology, etc.

Working modes

Function

Modes

Output power (load)

V-PP

CF

Monopolar cut

Pure cut

1 - 150 W (load: 700 Ω‌)

2.6 KV

1.5

Blend

1 - 100 W (load: 700 Ω‌)

4 KV

1.8

Ablation

1 - 100 W (load: 700 Ω‌)

4.2 KV

2.1

Monopolar coagulation

Spray

1 - 80 W (load: 700 Ω‌)

5.3 KV

7.4

Forced

1 - 100 W (load: 700 Ω‌)

5 KV

3.8

Bipolar

Standard coag

1 - 120 W (load: 200 Ω‌)

550 V

1.6

Basic parameters

Display

LED digital display

Dimensions

45 cm × 37 cm × 17 cm

Weight

8 kg

Input voltage

100 - 240 V - ± 10 %

Mains line frequency range

50 - 60 Hz

Power rating

1100 VA

Power consumption

≤ 1100 VA

Fuses (two)

5 A / 10 A

Working frequency

MONO: 4 MHz; BIP: 1 MHz

Monopolar RF leakage current

< 150 mA

Bipolar RF leakage current

< 50 mA

Ambient temperature range

5 ℃ - 40 ℃

Relative humidity

≤ 80 %

Atmospheric pressure

86 kPa - 106 kPa
