Application

Modular Design

Compatible Surgical Procedures

The ESU system supports laparoscopic surgery along with specific endoscopic procedures, making it versatile for a wide range of surgical applications.

Wide clinical applications, such as the general surgery, thoracic surgery, orthopedic surgery, cardiology, gynecology, urology (under water TUR), oncology, neurosurgery, etc.

Working modes

Function

Modes

Output power (load)

V-PP

CF

Monopolar cut

Pure cut

1 - 350 W (load: 800 Ω‌)

1.4 KV

1.4

Blend 1

1 - 200 W (load: 800 Ω‌)

1.72 KV

1.7

Blend 2

1 - 200 W (load: 800 Ω‌)

2.1 KV

2.5

Monopolar coagulation

Spray

1 - 80 W (load: 800 Ω‌)

2.8 KV

5.8

Forced

1 - 120 W (load: 800 Ω‌)

640 V

2.1

Bipolar

Standard coag

1 - 70 W (load: 200 Ω‌)

480 V

1.8

Basic parameters

Display

Digital display

Dimensions

45.2 cm × 36 cm × 16 cm

Weight

8.5 kg

Input voltage

100 - 240 V - ± 10 %

Mains line frequency range

50 - 60 Hz

Power rating

1100 VA

Power consumption

≤ 1100 VA

Fuses (two)

5 A / 10 A

Working frequency

416 KHz

Monopolar RF leakage current

< 150 mA

Bipolar RF leakage current

< 50 mA

Ambient temperature range

5 ℃ - 40 ℃

Relative humidity

≤ 80 %

Atmospheric pressure

86 kPa - 106 kPa
