Model

GX-30BE

GX-45BE

GX-65BE

GX-85BE

GX-125BE

GX-230BE

Cycle Mode

Forced convection

Function

Temp. Range

RT + 10 ~ 300℃

Temp. Resolution Ratio

0.1℃

Temp. Motion

± 1℃

Temp. Uniformity

± 2.5%

Structure

Inner Chamber

Mirror stainless steel

Outer Shell

Cold rolling steel, electrostatic spraying exterior

Insulation Layer

High quaility rock wool board (with CE)

Heater

stainless steel heater

Power Rating

0.8 kW

1.2 kW

1.6 kW

2.0 kW

2.3 kW

3.0 kW

Exhaust Hole

Φ 35 mm top (with function of test hole)

Controller

Temp. Control Mode

Two temperature section PID intelligent

Temp. Setting Mode

Touch button setting

Display

 LCD digital display

Timer

0-9999 min (with timing wait function)

Operation Function

Fixed temperature operation, fixed timing function, auto stop.

Additional Function

High precision digital independent temperature limiter,
4 grades 3 speed adjustable-speed fan
(GX230BE without fan speed adjustor),
sensor deviation correction, temperature overshoot
self-tuning, internal parameter locking, power-off parameter memory

Sensor

Pt100

Safety Device

Digital independent Temp. limiter, over temperature sound-light alarm.

Specification

Inner Chamber
Size (W × L × H)
(mm)

310 × 310 × 310

350 × 350 × 350

400 × 360 × 450

450 × 420
 × 450

500 × 450 × 550

600 × 500 × 750

Exterior Size
(W × L × H) (mm)

460 × 510
 × 695

500 × 550
 × 735

550 × 550
 × 840

590 × 610
 × 830

636 × 680
 × 915

735 × 835
 × 1115

Packing Size
(W × L × H) (mm)

540 × 575
 × 855

580 × 615
 × 895

635 × 625
 × 995

680 × 685
 × 1000

710 × 730
 × 1100

857 × 885
 × 1287

Volume

30 L

45 L

65 L

85 L

125 L

230 L

Shelf Number

5

6

8

8

11

17

Load per Rack

15 kg

Shelf Space

40 mm

Current Rating
(50 / 60 HZ)

AC 220 V /
3.6 A

AC 220 V /
5.5 A

AC 220 V /
7.2 A

AC 220 V /
9.0 A

AC 220 V /
10.5 A

AC 220 V /
13.6 A

NW / GW (kg）

33 / 37

37 / 43

44 / 49

50 / 56

60 / 66

94 / 120

Accessory

Shelf

2

Shelf Frame

4

Optional Accessories

Spare shelf, RS485 interface,
printer, program controller, U-disk storage, 3.5-inch color touch screen temperature controller.
