Non-vacuum Pulsation Type

Model

Single door

WY-100D

WY-150D

WY-200D

WY-300D

WY-400D

Double door

WY-100S

WY-150S

WY-200S

WY-300S

WY-400S

Capacity

100 L

150 L

200 L

300 L

400 L

Power

≤ 11 KW

≤ 14 KW

≤ 14 KW

≤ 17 KW

≤ 17 KW

Voltage

Three-phase, five-wire AC 380 V, 50 ~ 60 HZ

Rated working pressure

0.245 Mpa

Rated working temperature

144 ℃

Sterilization temperature

105 ℃ ~ 138 ℃

Temperature uniformity

< 2 ℃

Sterilization time setting range

0 ~ 120 min

Drying time setting range

0 ~ 240 min

Vacuum

N / A

Steam consumption (kg)

≤ 10

≤ 12

≤ 13

≤ 18

≤ 22

Water consumption (kg)

≤ 30

≤ 30

≤ 30

≤ 40

≤40

Water pressure

0.1 ~ 0.2 Mpa

External steam pressure

0.3 ~ 0.7 Mpa

Compressed air pressure

0.4 ~ 0.7 Mpa

Chamber volume (mm)

Ø 420 × 750

Ø 472 × 880

Ø 472 × 1150

Ø 620 × 995

Ø 620 × 1320

Outer dimension (mm)

1160 × 650 × 1680

1290 × 690 × 1680

1560 × 690 × 1680

1430 × 850 × 1760

1755 × 850 × 1760

Packing size

(L × W × H) (mm)

1350 × 780 × 1780

1570 × 840 × 1850

1740 × 840 × 1850

1610 × 990 × 1900

1935 × 990 × 1900

Gross / Net weight

380 / 420 kg

450 / 490 kg

490 / 530 kg

560 / 610 kg

630 / 670 kg

Vacuum Pulsation Type

Model

Single door

WY-100DM

WY-150DM

WY-200DM

WY-300DM

WY-400DM

Double door

WY-100SM

WY-150SM

WY-200SM

WY-300SM

WY-400SM

Capacity

100 L

150 L

200 L

300 L

400 L

Power

≤ 14 KW

≤ 17 KW

≤ 17 KW

≤ 20 KW

≤ 20 KW

Voltage

Three-phase, five-wire AC 380 V, 50 ~ 60 HZ

Rated working pressure

0.245 Mpa

Rated working temperature

144 ℃

Sterilization temperature

105 ℃ ~ 138 ℃

Temperature uniformity

< 2 ℃

Sterilization time setting range

0 ~ 120 min

Drying time setting range

0 ~ 240 min

Vacuum

- 0.086 Mpa

Steam consumption (kg)

≤ 11

≤ 13

≤ 15

≤ 20

≤ 25

Water consumption (kg)

≤ 190

≤ 190

≤ 190

≤ 200

≤200

Water pressure

0.1 ~ 0.2 Mpa

External steam pressure

0.3 ~ 0.7 Mpa

Compressed air pressure

0.4 ~ 0.7 Mpa

Chamber volume (mm)

Ø 420 × 750

Ø 472 × 880

Ø 472 × 1150

Ø 620 × 995

Ø 620 × 1320

Outer dimension (mm)

1160 × 650 × 1680

1290 × 690 × 1680

1560 × 690 × 1680

1430 × 850 × 1760

1755 × 850 × 1760

Packing size

(L × W × H) (mm)

1350 × 780 × 1780

1570 × 840 × 1850

1740 × 840 × 1850

1610 × 990 × 1900

1935 × 990 × 1900

Gross / Net weight

380 / 420 kg

450 / 490 kg

490 / 530 kg

560 / 610 kg

630 / 670 kg
