Field of application

Erythrocyte sedimentation rate analysis

Measuring principle

Infrared sensor

Analysis result

Westergren ESR value (mm / hr)

Throughput

Up to 80 samples per hour

Reading channels

20 / 40

Loading capacity

20 / 40

Loading pattern

Random

Measuring time

30 minutes or 60 minutes selectable

Sample interval

3 minutes

Measurement range

0-140 mm / h

Temperature compensation

Refer to 18C automatically (selectable)

Reading resolution

0.2 mm

Result resolution

1mm / 1h, 1mm / 2h

Display

Color LCD screen

Input

Touch screen

Interface

RS-232 serial port

Print

Internal thermal recorder

Power supply

AC 220 ± 22 V; 50 ± 1 Hz

Operation conditions

Temperature 10 - 30℃, Humidity < 80%

Dimension

365 mm * 300 mm * 180 mm ( L * W * H )

Net weight

11 Kg
