Model

JERRY-I

Size

209 mm × 104 mm × 47.5 mm

Net weight

655 g

Display

Color TFT - LCD / touch screen

AC power adaptor

Input: 100 ~ 240 V AC, 50 / 60 Hz, 0.7 A

Output: DC 5 V, 2 A

Battery

Li-ion rechargeable battery, 3.7 V / 7200 mAH

Operating time

15 hours with full battery capacity

(condition: 25 ℃, NIBP working period is 15 minutes)

Recharge time

10 hours

ECG

Input: 5- lead ECG cable, standard AAMI cable connector

Lead selection: I, II, III, avR, avL, avF, C

Gain selection: × 1, × 2, × 4, × 8

Sweep speed: 12.5, 25, and 50 mm/s

Frequency response:

none filter: 0.05 ~ 100 Hz (- 3 dB)

filter: 0.5 ~ 40 Hz (- 3 dB)

Calibration signal: 1 mV square wave

Heart Rate

Measuring range: 20 bpm ~ 300 bpm

Renew time: 1 time per beat

Accuracy: ± 1 bpm

Alarm mode: audible and visual alarm

SpO2

Measuring range: 0 % ~ 100 %

Resolution: 1 %

Accuracy: ± 2 % (90 % ~ 99 %),  ± 3 % (70 % ~ 89 %), unspecified (0 % ~ 69 %)

Pulse rate

Measuring and alarm range: 20 ~ 300 bpm

Resolution: 1 bpm

Accuracy: ± 1 bpm

NIBP

Method: oscillometric

Mode: manual, auto, stat

Measuring interval in auto mode: 1, 2, 3, 5, 10, 15, 20, 30, 45, 60 (min)

Measuring period in stat mode: 5 min

Cuff pressure range: 0 mmHg ~ 300 mmHg

Pulse rate range: 30 bpm ~ 250 bpm

Measurement range:

Adult 30 mmHg ~ 255 mmHg

Pediatric 30 mmHg ~ 160 mmHg

Over-pressure protection:

Adult 300 mmHg

Pediatric 220 mmHg

Pressure resolution: 1 mmHg

TEMP

Input: body surface thermal-sensitive resistor temperature sensor

Measuring range: 0 ℃ ~ 50 ℃

Accuracy: ± 0.1 ℃

EtCO2 (optional)

Measuring Range: 0 ~ 150 mmHg

Resolution: 1 mmHg

Accuracy: ± 2 mmHg @ < 5.0 % CO2

Storage and review

Maximum data quantity: 3888 groups

Maximum trend time: continuous 129.6 hours

Environment

Temperature:

Operation: 0 ℃ ~ 45 ℃

Transportation and storage: - 25 ℃ ~ 85 ℃

Humidity:

Operation: 30 % ~ 85 %

Transportation and storage: 30 % ~ 95 % (non-condensing)
