Model

BL-99

Microscope type

Galilean stereoscopic microscope

Magnification selection

5 steps by drum rotation

Eyepiece

12.5X

Magnification ratio (field of view)

6X (Φ33 mm), 10X (Φ22.5 mm), 16X (Φ14 mm), 25X (Φ8.8 mm), 40X (Φ5.5 mm)

Pupillary adjustment

50 mm ~ 82 mm

Diopter adjustment

± 7D

Side shift (base)

110 mm

Depth shift (base)

90 mm

Height shift (base)

30 mm

Height shift (chin rest)

80 mm

Fixation target (chin rest)

Red LED

Slit width

0 ~ 14 mm continuous (at 14 mm, slit becomes a circle)

Slit height

1 ~ 14 mm continuous

Slit angle

0° ~ 180° adjustable

Slit inclination

5°, 10°, 15°, 20°

Diameter of light spot

Φ14 mm, Φ10 mm, Φ5 mm, Φ3 mm, Φ2 mm, Φ1 mm, Φ0.2 mm and 1 ~ 14 mm continuous

Filter

Heat absorption, grey, red-free, cobalt blue, built-in yellow

Illumination bulb

LED

Input voltage

100 V - 240 V AC

Frequency

50 Hz / 60 Hz

Power consumption

20 VA
