Model

RZ-350

RZ-350A

RZ-350B

RZ-350C

Module

configuration

High-frequency

electrosurgical system

√

√

√

√

Argon plasma system

√

√

-

-

Bipolar plasmakinetic system

√

-

√

-

Tissue closure system

√

√

√

√

Working modes

High-frequency

electrosurgical system

Monopolar cut (Pure cut): 1 ~ 350 W (load: 500 Ω)

Monopolar cut (Blend 1): 1 ~ 250 W (load: 500 Ω)

Monopolar cut (Blend 2): 1 ~ 150 W (load: 500 Ω)

Monopolar cut (Blend 3): 1 ~ 100 W (load: 500 Ω)

Monopolar coagulation (Spray coag): 1 ~ 80 W (load: 200 Ω)

Monopolar coagulation (Forced coag): 1 ~ 120 W (load: 200 Ω)

Monopolar coagulation (Soft coag): 1 ~ 120 W (load: 125 Ω)

Bipolar coagulation (Standard coag): 1 ~ 120 W (load: 75 Ω)

Tissue closure system

Soft tissue closure: 1 ~ 120 W (load: 300 Ω)

Bipolar plasmakinetic system

Bipolar plasma resection: 1 ~ 300 W (load: 125 Ω)

Bipolar plasma electrocoagulation: 1 ~ 200 W (load: 75 Ω)

Argon plasma system

Argon spray coagulation: 1 ~ 80 W (load: 200 Ω)

Pulse spray coagulation: 1 ~ 80 W (load: 200 Ω)

Fast pulse spray coagulation: 1 ~ 80 W (load: 200 Ω)

Output power accuracy

± 20 %

Output frequency

380 - 570 kHz, accuracy ± 10 %

Peak coefficient accuracy

± 20 %

Argon flow control system

Flow rate range: 0.1 - 15.0 L/min

Regulating step: 0.1 L/min

Pressure of nozzle: 0 - 1 MPa

Argon purity: ≥ 99.99 %

Argon capacity: 4 L

Pressure of inputting: 0.2 - 0.65 MPa

Display

Separate 5” LCD touch screen × 3 pcs

Input power

1100 VA

Maximum output power

350 W

Power supply

AC 100 - 240 V, 50 / 60 Hz

Environmental temperature range

5 ℃ ~ 40 ℃

Relative humidity range

≤ 80 %

Atmosphere pressure range

86.0 ~ 106.0 kPa

Standard Accessories

Model

RZ-350

RZ-350A

RZ-350B

RZ-350C

Mainframe

1 unit

1 unit

1 unit

1 unit

Power cable

1 pc

1 pc

1 pc

1 pc

Neutral electrode

10 pcs

10 pcs

10 pcs

10 pcs

Electrode plate cable

1 pc

1 pc

1 pc

1 pc

Endoscopic APC probe

2 pcs

-

-

-

Endoscopic ablation electrode

1 pc

-

-

-

Argon electrosurgical pencil (open)

1 pc

1 pc

-

-

Argon electrosurgical pencil (endoscope)

1 pc

1 pc

-

-

Argon arc tester

1 pc

-

-

-

Bipolar plasma electrode

1 pc

-

1 pc

-

Disposable flushing tube

1 pc

1 pc

1 pc

1 pc

Tissue closure forcep (10 mm open)

1 pc

1 pc

1 pc

1 pc

Tissue closure forcep (5 mm endoscope)

-

1 pc

1 pc

-

Electrosurgical pencil

1 pc

1 pc

1 pc

1 pc

High frequency connection cable

1 pc

1 pc

-

1 pc

Bipolar electrode

-

-

-

1 pc

Bipolar electrode cable

-

-

-

1 pc

Foot switch

1 pc

1 pc

1 pc

1 pc

Argon pressure reducing valve

1 pc

1 pc

-

-

Argon cylinder (4 L)

2 pcs

1 pc

-

-

Dedicated trolley

1 pc

1 pc

1 pc

Optional
